1.Measurement process video
Face 1: Has two sides, requires two prisms, and the measurement takes 2 minutes and 20 seconds.
Face 2: Measurement took 40 seconds.
Face 3: Measurement took 45 seconds.
Face 4: Measurement took 45 seconds.
Measurement conclusion:
The estimated total measurement time is approximately 6 minutes, including flipping, measurement depth, etc. For batch testing, it is recommended to prepare fixtures, which can effectively reduce the time for moving, flipping the workpiece.
Machine: COBEKK recommends the AM600 fully automatic image measuring machine. The specific measurement configuration includes a 205 CCD, 0.7-4.5 automatic zoom coaxial optical lens, and point spectrum.
