| Masurium | Angle | X biased | Y biased | Hht1 | Hht2 | Hht3 | Hht4 | Incline |
| Feature name | Angle | X distance | Y distance | Altitude | Altitude | Altitude | Altitude | Result1 |
| Standard value | 0 | 457.3 | 36.1 | 190 | 190 | 190 | 190 | 0 |
| Upper tolerance | 0.05 | 20 | 20 | 50 | 50 | 50 | 50 | 30 |
| Lower tolerance | -0.05 | -50 | -20 | -50 | -50 | -50 | -50 | -30 |
| Specification upper limit | 0.05 | 477.3 | 56.1 | 240 | 240 | 240 | 240 | 30 |
| Specification lower limit | -0.05 | 407.3 | 16.1 | 140 | 140 | 140 | 140 | -30 |
| Maximum value | 0.0418 | 475.1676 | 30.2889 | 222.9996 | 209.4955 | 215.4999 | 223.5031 | 24.5056 |
| Minimum value | 0.0234 | 468.9463 | 18.1535 | 195.5032 | 199.4934 | 198.9975 | 196.4951 | 14.4959 |
| Average value | 0.030066667 | 471.458 | 24.43916 | 207.0007333 | 203.3309667 | 209.1649333 | 209.1649333 | 18.8319 |
| Range | 0.0184 | 6.2213 | 12.1354 | 27.4964 | 10.0021 | 16.5024 | 27.008 | 10.0097 |
| OK | 0.025 | 468.9463 | 30.2889 | 202.4994 | 201.004 | 215.4999 | 207.4966 | 14.4959 |
| OK | 0.0234 | 470.2601 | 18.1535 | 195.5032 | 209.4955 | 212.9974 | 196.4951 | 17.4942 |
| OK | 0.0418 | 475.1676 | 24.8751 | 222.9996 | 199.4934 | 198.9975 | 223.5031 | 24.5056 |
| Masurium | Angle | X biased | Y biased | Hht1 | Hht2 | Hht3 | Hht4 | Incline |
| Feature name | Angle | X distance | Y distance | Altitude | Altitude | Altitude | Altitude | Result1 |
| Standard value | 0 | 457.3 | 36.1 | 190 | 190 | 190 | 190 | 0 |
| Upper tolerance | 0.05 | 20 | 20 | 50 | 50 | 50 | 50 | 30 |
| Lower tolerance | -0.05 | -50 | -20 | -50 | -50 | -50 | -50 | -30 |
| Specification upper limit | 0.05 | 477.3 | 56.1 | 240 | 240 | 240 | 240 | 30 |
| Specification lower limit | -0.05 | 407.3 | 16.1 | 140 | 140 | 140 | 140 | -30 |
| Maximum value | 0.0418 | 475.1676 | 30.2889 | 222.9996 | 209.4955 | 215.4999 | 223.5031 | 24.5056 |
| Minimum value | 0.0234 | 468.9463 | 18.1535 | 195.5032 | 199.4934 | 198.9975 | 196.4951 | 14.4959 |
| Average value | 0.030066667 | 471.458 | 24.43916 | 207.0007333 | 203.3309667 | 209.1649333 | 209.1649333 | 18.8319 |
| Range | 0.0184 | 6.2213 | 12.1354 | 27.4964 | 10.0021 | 16.5024 | 27.008 | 10.0097 |
| NG | 0.025 | 468.9463 | 30.2889 | 202.4994 | 201.004 | 215.4999 | 207.4966 | 14.4959 |
| NG | 0.0234 | 470.2601 | 18.1535 | 195.5032 | 209.4955 | 212.9974 | 196.4951 | 17.4942 |
| NG | 0.0418 | 475.1676 | 24.8751 | 222.9996 | 199.4934 | 198.9975 | 223.5031 | 24.5056 |
Based on the provided samples, measure the chip offset and horizontal inclination
Machine: We recommend the AG series imaging system, combined with the i-Sobit software.
